Allen Bradley 22C-D142A103 PowerFlex
The 22C-D142A103 PowerFlex 400 adjustable frequency AC drive from Allen-Bradley. This drive is specifically designed for industrial fan and pump applications. It has an input voltage requirement of 340-528 Volts AC, 3-Phase, and provides an output voltage of 0-460 Volts AC, 3-Phase. It delivers an output current of 142 Amperes @ 45 degrees Celsius, 128 Amperes @ 50 degrees Celsius, and a power of 100.0 Horsepower or 75.0 Kilowatts. This drive comes with an RS-485 communication interface - it also supports Sinusoidal Pulse Width Modulation (PWM) and Volts/Hertz control.
Specifications
ManufacturerRockwell Automation
Input Voltage380-528VAC
Part Number/Catalog No.22C-D142A103
BrandAllen-Bradley
Product Family:PowerFlex 400 for Fan and Pump applications
Input Phase:3-Phase
Input Current:150 A
Output Voltage:0-460VAC
Output Current:142 A @ 45o C; 128 @ 50o C
Output Power:75 HP (55 kW)
Output Frequency:0-320 Hz (programmable)
Carrier Frequency:2…8 kHz, Drive rating based on 4 kHz
Embedded I/O:Discrete Inputs: Seven (7) Sink / Source Discrete Outputs: One (1) Open Output; Two (2) Form C Contacts Analog Input: Two (2) Analog Input 0-10VDC; 0- 20mA Analog Output: Two (2) Analog Input 0-10VDC; 0- 20mA
Installation:Panel Mount
Enclosure Rating:IP20 / NEMA UL Open Type
Control Method:Sinusoidal PWM; Volts / Hertz
Built-in communication port:RS485
Product Line:Powerflex 400
Drive Type:Fan & Pump
Horsepower:100
Phase:Three-Phase
Enclosure:Panel Mount - IP30, NEMA/UL Type 7
Amperage:142 Amps
Communication:Modbus RTU, P1-Floor, FLN, Metasys N2, and DSI.
Frame Size:E
Power Dissipation:2043 Open IP20 Watts
Flange Mount:None
Description:
Part #:22C-D142A103
Category:Drives
Subcategory:Drive
Weight:100.00 lbs
Drive Type:PowerFlex 400,
Voltage Rating:480 VAC, 3 PHASE
Rating:142 AMP, 75 kW, 100 HP,
Enclosure:Panel Mount - IP30 NEMA Type 1,
HIM:FIXED KEYPAD
Emission Class:NOT FILTERED
Version:RS485
