Allen Bradley 22B-D010N104 PowerFlex
The Allen-Bradley 22B-D010N104 is a PowerFlex 4 Variable Frequency Drive (VFD). This VFD is powered with an input voltage rating of 342-528, 3-phase with applicable motor output of 10.5 A and Power of 4.0 kW (5.0 HP).
Specifications
Filter:Without CE Compliant Filter
Brand:Allen-Bradley
Manufacturer:Rockwell Automation / Allen-Bradley
Input Voltage:380-480VAC
Input Phase:3-Phase
Rated Current output:10.3 A
Rated Power:4.0 kW (5.0 HP)
Installation:Panel Mount
Enclosure Rating:IP20 / NEMA UL Type Open
Keypad:LED Keypad
Built-in Communication port:RS485
I/O Terminal:Discrete Inputs: 3 fixed for START/STOP/REV; 4 Fully Programmble Discrete Outputs: 4 fully programmable; Analog Input: 2 0…10V or 4…20 mA (unipolar) 1 +/- 100V (bipolar) Discrete Output: 1 - N.O/N.C. dry contact; 2 Digital / Optocoupler
Part Number/Catalog No.:22B-D010N104
Product Line:Powerflex 40
Voltage:480 Volts AC
Horsepower:5 Horsepower
Amperage:10.0 Amps
Phases:3
Communication:RS-485
Input Type:Keypad
Preset Speeds:8
Frame Size:B
Enclosure:IP20, NEMA/UL
Dimensions:180.07 x 100 x 136 millimeters
Product:
Part #:22B-D010N104
Category:Drives
Subcategory:Drive
Weight:4.15 lbs
Current:10.5 AMP
Phases:3
KW/HP:4 KW / 5 HP
Voltage:480 VAC
Product Type:AC DRIVE
Frequency Type:Adjustable
Keypad:Fixed
IP Rating:IP 20
Filtered:No
Mounting Style:Panel Mount
Product Family:POWERFLEX 40
Brake:Standard
