Allen Bradley 20BC170A0ANNANC0 PowerFlex 700 AC Drive 20B
PowerFlex 700 AC Drive 20B
PowerFlex700 AC Drive, 400 VAC, 3 PH, 170 Amps, 90 kW Normal Duty, 75 kW Heavy Duty, IP20 / Type 1, with conformal coating, No HIM (Blank Plate), No Brake IGBT, Without Drive Mounted Brake Resistor, Second Environment Filter per CE EMC directive (89/336/EEC), No Communication Module, Vector Control with 24V I/O, No Feedback.
Manufacturer : Rockwell Automation
Brand : Allen-Bradley
Part Number/Catalog No. : 20BC170A0ANNANC0
Degree of protection (IP) : IP20
Shock : 15 G peak for 11 ms duration (±1.0 ms)
Vibration : 0.152 mm (0.006 inch) displacement, 1 G peak
Number of analogue outputs : 2
Mains voltage : 400 V
Integrated breaking resistance : No
Number of digital inputs : 6
Number of digital outputs : 3
Number of analogue inputs : 2
Supporting protocol for DeviceNet : Yes
Max. output frequency : 420 Hz
Supporting protocol for EtherNet/IP : Yes
Line voltage, nom : 400V @ 380...480V drive rating, 400V nominal motor voltage
Mains frequency : 50 Hz
Efficiency : 97.5% at rated amps, nominal line volts
Number of phases output : 3
Number of phases input : 3
Relative symmetric net voltage tolerance : 10 %
With control element : Yes
Supporting protocol for LON : Yes
Supporting protocol for TCP/IP : Yes
Supporting protocol for PROFIBUS : Yes
Supporting protocol for CAN : Yes
Supporting protocol for Modbus : Yes
Input frequency tolerance : 47 Hz
