Allen Bradley 1794-L34 FlexLogix controller

Allen-Bradley 1794-L34 is a FlexLogix controller.

Item no.:
1794-L34
Payment:
T/T,Western Union
Market price:
$66
Product origin:
USA
Color:
New and original
Goods stock:
30
Lead Time:
In stock

Inquiry now

product introduction

Allen-Bradley 1794-L34 is a FlexLogix controller.

Description For 1794-L34

The Allen-Bradley 1794-L34 is a FlexLogix controller. This controller has 512Kbytes user memory, powered by an external supply voltage of 24VDC. This controller has One (1) serial communication port and supports installation of communication adapters to connect to Ethernet I/P, EeviceNet and ControlNet communication networks

The 1794-L34 features an embedded serial communication interface that supports ASCII and DF1 protocol. ASCII is typically used for communicating with barcode readers while DF1 may be used to used with operator terminals such as PanelView Graphic Terminals as well as Supervisory Control and Data Acquisition (SCADA) systems. It may be installed with communication adapters such has the 1788 communication adapters to become compatible with Ethernet, DeviceNet and ControlNet communication networks.

The 1794-L34 comes with an internal user memory amounting to 512 Kbytes. It is powered by an external supply voltage of 24VDC, nominal with acceptable voltage range of 19-31.2 VDC, including 5% ac ripple. It requires a FlexBus current of 653mA maximum @ 5.1V dc and power dissipation of 25.5W maximum at 19.2V and 20.4W maximum at 24V dc while the controllers Thermal dissipation is 87BTU/hour @ 19.2V.

To comply with CSA requirements, a Separated Extra Low Voltage (SELV) power supply such as 1794-PS3 or 1794-PS13 may be used. When terminating power supply input, use #22 to #14 AWG (0.324 to 2.08 sq. mm) stranded wires and tighten connections with 5 to 7 inch-pounds (0.6 to 0.8Nm) Torque.

The embedded serial cable can be custom fabricated however, Allen-Bradley manufactured cables may be used such as 1756-CP3 or 1747-CP3 directly to controller. It may also be interfaced with 1761-NET-AIC for isolation. When interface with the 1761-NET-AIC, applicable serial communication cables are 1761-CBLPM02 and 1761-CBLPA00.

Application installation orientation for this module is either horizontal or vertical mountinh via a panel mount or DIN rail (particularly a 35 x 7.55 millimeters steel DIN rail). The 1794-L34 can handle up to 8 tasks but only 1 can be continuous. This controller supports event tasks, which are consumed tag trigger as well as EVENT instructions. Aside from DeviceNet, EtherNet/IP, and ControlNet communications, the 1794-L34 can also communicate using serial communication, DH-485, and Modbus via ladder routine. 32 connections each can be made over EtherNet/IP and ControlNet.

Allen Bradley's 1768-PB3 is a CompactLogix power supply. The 1768-PB3 is powered through the CompactLogix backplane. By using this backplane, the 1768-PB3 power supply is compatible with the 1768 and 1769 controllers, input/output modules, and power supply

Product specification

Model Number: 1794-L34

Product name: 1794-L34

Payment :Paypal\TT\Western Union\ Trade Assurance

MOQ :1PCS

Package :Carton Package

Shipping By DHL\UPS\Fedex\EMS\TNT\Aramex

Service :24 Hours Online Service

Lead time :5-7 Days

Condition :100% Original

Original factory:Allen-Bradley 1794-L34 In stock best price

Shipping term: TNT DHL FEDEX UPS

Warranty: 12 Months

Condition: Original & new
