Allen Bradley 1762-OW8 Output Module Ser

Allen-Bradley 1762-OW8 output module is a solid-state type of industrial output module.

Item no.:
1762-OW8
Payment:
T/T,Western Union
Market price:
$66
Product origin:
USA
Color:
New and original
Goods stock:
30
Lead Time:
In stock

Inquiry now

product introduction

Allen-Bradley 1762-OW8 output module is a solid-state type of industrial output module.

Description For 1762-OW8

The Allen-Bradley 1762-OW8 output module is a solid-state type of industrial output module. It is part of the Allen-Bradley MicroLogix 1200 series and it can be used as part of a MicroLogix control system. The 1762-OW8 output module can be mounted on a DIN Rail and it is meant to be used in clean and dry industrial environments that have Pollution Degree 2 pollution ratings. This solid-state output module needs to be protected from ESD or electrostatic discharge at all times during storage, installation, operation, and maintenance. The 1762-OW8 solid-state output module has 8 output channels and it can operate at 32 to 131 degrees Fahrenheit.

The 1762-OW8 Output Module has an AC/DC normally-open relay voltage category with an operating range of 5 to 265 Volts AC and 5 to 125 Volts DC. It has a maximum bus current draw of 80 mA at 5 Volts DC (0.40 Watts) and 90 mA at 24 Volts DC (2.16 Watts). Its maximum continuous current per common is 8 A, and it is 16 A per module. This device should be installed 6 modules away from the host device’s power supply. It houses two isolated output groups - outputs 0 to 3, and outputs 4 to 7. The 1762-OW8 Relay Output Module can be mounted on the EN 50 022 35 x 7.5 millimeters or the EN 50 022 35 x 15 millimeters DIN rails. For installation in high vibration or shock environments, use DIN rail end anchors. For greater vibration requirements, opt for panel mounting. For both DIN rail and panel mounting, keep debris from falling into the 1762-OW8 module to avoid any damage.

The 1762-OW8 is a MicroLogix Relay output expansion module. This expansion module feature Two (2) output groups, with each group having Four (4) outputs each. Group 0 is consisted of Channels 0-3 while Group 1 is comprised of Channels 4-7. This module is compatible for enhancing the embedded output capability of MicroLogix 1100, 1200 and 1400 Programmable Logic Controller (PLC).

This module features Eight (8) relay contact outputs that is designed to operate at voltage categories of 5 to 265VAC and 5 to 125VDC voltage ranges. This module connects to the MicroLogix bus via the provided ribbon cable that is terminated to the adjacent expansion module or the MicroLogix base controller. The signal delay time exhibited by each channel of the module is at 10 ms for both ON to OFF and OFF to ON transitions. Each output point is rated for 2.5 A continuous current, Continuous Current per common of 8A and Continuous Current per module of 16A.

Allen Bradley's 1768-PB3 is a CompactLogix power supply. The 1768-PB3 is powered through the CompactLogix backplane. By using this backplane, the 1768-PB3 power supply is compatible with the 1768 and 1769 controllers, input/output modules, and power supply

Product specification

Model Number: 1762-OW8

Product name: 1762-OW8

Payment :Paypal\TT\Western Union\ Trade Assurance

MOQ :1PCS

Package :Carton Package

Shipping By DHL\UPS\Fedex\EMS\TNT\Aramex

Service :24 Hours Online Service

Lead time :5-7 Days

Condition :100% Original

Original factory:Allen-Bradley 1762-OW8 In stock best price

Shipping term: TNT DHL FEDEX UPS

Warranty: 12 Months

Condition: Original & new
