ALLEN BRADLEY 1762-OA8 Brand New Original PLC Inverter In Stock Industrial Automation module

The Allen-Bradley 1762-OA8 is a solid-state output module. Its non-operating temperature varies from -40 to 185 degrees Fahrenheit while its operating temperature varies from 32 to 131 degrees Fahrenheit. This module also complies with the NEMA ICS 2-230, EN50081-2 Class A, IEC1000-4-2, and the IEC1000-4-3 standards. The 1762-OA8 operates on 85 to 256 Volts AC at 47 to 63 Hertz. This module has 8 outputs. Its maximum bus current is 115 mA at 5 Volts DC and its maximum heat dissipation is 2.9 W. The maximum voltage drop of the 1762-OA8 is 1.5 Volts at 0.5 Amps while the minimum on-state current of this module is 10 mA.

The 1762-0A8 must be well-grounded on a proper mounting surface, like a metal panel. Refer to Allen-Bradley’s wiring and grounding guidelines for more information. Ensure that the module is free of all metal fragments before operation because these fragments could cause damage when the power is applied. Make sure to keep the finger-safe cover in place when wiring the terminal block. Once removed, the cover cannot be put back on the module because the wires’ position will prevent it. The 1762-0A8 is compatible with MicroLogix 1100, MicroLogix 1200, and MicroLogix 1400 systems.

Allen Bradley Main Products:

1.SLC500:1747/1746 series
2.MicroLogix: 1761/1763/1762/1766/1764 series
3.CompactLogix: 1769/1768 series
4. The ControlLogix: 1756/1794/1760/1788 series
5. PLC-5:1771/1785 series
6.2711,2711P PanelView man-machine interface, touch screen, operation panel
7. ProSoft: MVI69 / PS69 / MVI56 / MVI94 / MVI71 / MVI46/3150
