Allen-Bradley 1756-OV32E ControlLogix DC Electronically-Fused Sinking Output Module

Allen-Bradley 1756-OV32E ControlLogix DC Electronically-Fused Sinking Output Module

The 1756-OV32E ControlLogix DC Electronically-Fused Sinking Output Module by Allen-Bradley is a chassis-located output module with 32 electronically-fused and sinking outputs. It has an operational voltage range of 10-30V DC with a maximum signal time delay of 300μs for OFF to ON, and 1ms for ON to OFF. The 1756-OV32E draws 390mA current at 5.1V and 2mA at 24V and the total output rating on the backplane is 2.04W. When operational, the 1756-OV32E has a thermal dissipation of 20.1 BTU/hr and a 1mA current leakage on each output point. In the ON state, the circuit will lose 350mV DC at 0.5A and the maximum current on each point is 0.5A at 50 °C totaling 16A on the whole module at 50 °C.

Product specification

Brand: Allen Bradley

Warranty :180 days

Origin: USA

Lead time: STOCK

Date code: NEW or used

Packaging :Standard Exportation Packing

Shipping by :DHL\UPS\Fedex\EMS\HK Post

Module number : 1756-OV32E

Our Services:

1、 All our products are new and original, and of good quality.

2、 Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4、 All inquiries will be valued and will reply in 24 hours.

5、 Fast shipping, and good after-sale service

6、 We will ship the items within 1-3 working days after the payment is received.

7、 Good package to protect the products.

More Products In Stock:
